58

Fabric OS Encryption Administrator’s Guide (DPM)

53-1002922-01

Configuring encryption storage targets

2

FIGURE 41

Select Target dialog box

The dialog box contains the following information:

Target Port WWN: The world wide name of the target port in the same fabric as the
encryption engine.

Target Port Name: The name of the target port in the same fabric as the encryption
engine.

Target Node WWN: The world wide name of the target node in the same fabric as the
encryption engine.

Target Node Name: The name of the target device.

Targets list: Options are: Tape and Disk.

NOTE

The Targets list does not show targets that are already configured in the encryption group.

6. Select a target from the list. (The Target Port WWN and Target Node WWN fields contain all

target information that displays when using the nsShow command.) You can also enter WWNs
manually, for example, to specify a target that is not on the list.

7. Select a target type from the Type list, then click Next.

The Select Hosts dialog box displays. (Refer to

Figure 42

.) You can configure hosts for selected

target device ports. All hosts that are in the same fabric as the encryption engine are listed.

NOTE

The selected target and initiator port must be in the same zone, or an error will result.
