Fabric OS Encryption Administrator’s Guide (DPM)
213
53-1002922-01
Single fabric deployment - HA cluster
4
Single fabric deployment - HA cluster
shows an encryption deployment in a single fabric with dual core directors and several
host and target edge switches in a highly redundant core-edge topology.
FIGURE 95
Single fabric deployment - HA cluster
Target
Edge
Switch
Target
Edge
Switch
Target
Cluster Link
Cluster Link
Management Link
Management Link
Ciphertext
Cleartext
Dedicated Cluster
Network
LAN
Key Management
Appliance
or Key Vault
Management
Station
(DCFM)
Target
Target
Edge
Switch
Core
Host Edge
Switch
Host Edge
Switch
Host Edge
Switch
Host
Host
Encryption
Switch
Encryption
Switch
Virtual
Initiator
Virtual
Initiator
Virtual
Target
Virtual
Target
Management
Network
LAN
