CAUTION

For the ICX 6650 devices, be sure that the airflow direction of the power supply unit
matches that of the installed fan tray. The power supplies and fan trays are clearly
labeled with either a green arrow with an "E", or an orange arrow with an "I."

VORSICHT

Vergewissern Sie sich bei den ICX 6650-Geräten, dass die Luftstromrichtung des Netzteils der
der eingebauten Lüftereinheit entspricht. Die Netzteile und Lüftereinheiten sind eindeutig mit
einem grünen Pfeil und dem Buchstaben "E" oder einem orangefarbenen Pfeil mit dem
Buchstaben "I" gekennzeichnet.

MISE EN GARDE Pour les équipements de type ICX 6650, veillez à ce que le sens de circulation de l'air du bloc

d'alimentation corresponde à celui du tiroir de ventilation installé.

Les blocs d'alimentation et les tiroirs de ventilation sont étiquetés d'une flèche verte avec un " E
" ou d'une flèche orange avec un " I ".

PRECAUCIÓN

En el caso de dispositivos ICX 6650, asegúrese de que la dirección del flujo de aire de la
unidad de alimentación se corresponda con la de la bandeja del ventilador instalada. Los
dispositivos de alimentación y las bandejas del ventilador están etiquetadas claramente con
una flecha verde y una "E" o con una flecha naranja y una "I".

CAUTION

For the ICX 6650 devices, be sure that the airflow direction of the fan tray matches that
of the installed power supply unit. The power supplies and fan trays are clearly labeled
with either a green arrow with an "E", or an orange arrow with an "I."

VORSICHT

Vergewissern Sie sich bei den ICX 6650-Geräten, dass die Luftstromrichtung der Lüftereinheit
der des eingebauten Netzteils entspricht. Die Netzteile und Lüftereinheiten sind eindeutig mit
einem grünen Pfeil und dem Buchstaben "E" oder einem orangefarbenen Pfeil mit dem
Buchstaben "I" gekennzeichnet.

MISE EN GARDE Pour les équipements de type ICX 6650, veillez à ce que le sens de circulation de l'air du tiroir

de ventilation corresponde à celui du bloc d'alimentation installé.

Les blocs d'alimentation et les tiroirs de ventilation sont étiquetés d'une flèche verte avec un " E
" ou d'une flèche orange avec un " I ".

PRECAUCIÓN

En el caso de dispositivos ICX 6650, asegúrese de que la dirección del flujo de aire de la
bandeja del ventilador se corresponda con la de la unidad de alimentación. Los dispositivos de
alimentación y las bandejas del ventilador están etiquetadas claramente con una flecha verde y
una "E" o con una flecha naranja y una "I".

CAUTION

If you do not install a power supply in a slot, you must keep the slot panel in place. If you
run the device with an uncovered slot, the system will overheat.

VORSICHT

Wenn Sie in einem Einschub kein Netzteil einsetzen, müssen Sie die Blende im Einschub
lassen. Der Betrieb des Geräts mit einem offenen Einschub kann zur Überhitzung des Systems
führen.

MISE EN GARDE Si vous n'installez pas de bloc d'alimentation dans un emplacement, vous devez laisser le

cache de protection en place. Si vous faites fonctionner l’équipement avec un emplacement
vide, sans cache, le système risque de surchauffer.

PRECAUCIÓN

Si no hay ninguna fuente de alimentación instalada en una ranura, debe dejar la tapa
correspondiente puesta en la ranura. Si pone en funcionamiento el dispositivo con una ranura
descubierta, el sistema se sobrecalentará.

Brocade ICX 6650 Cautions and Danger Notices

Brocade ICX 6650 Hardware Installation Guide

87

53-1003083-01
