Managing the Brocade ICX 6650

Managing temperature settings.......................................................................................57

Removing MAC address entries..................................................................................... 59

Displaying Brocade ICX 6650 CPU usage......................................................................59

Hardware maintenance schedule....................................................................................60

Replacing a copper or fiber-optic module....................................................................... 60

FRU removal and replacement procedures.................................................................... 62

Replacing a power supply unit........................................................................................ 63

Replacing fan trays......................................................................................................... 65

Managing temperature settings

The device contains temperature sensors that the software reads based on a configurable device poll
time. To protect the device from overheating, the following temperature threshold levels exist:

The warning level is the temperature at which the device generates a syslog message and SNMP
trap. It is configurable.

The shutdown level is the temperature at which the device reboots. It is set by the device and is not
configurable.

The fan speed settings are set by the device, and are not configurable.

Displaying the temperature

To display the temperature of a device, enter the show chassis command at any level of the CLI.

NOTE
The temperature displayed by the show chassis command reflects the temperature of the board inside
the device.

ICX6650-64 Router#show chassis

The stack unit 1 chassis info:

Power supply 1 (NA - AC - Regular) present, status ok

Power supply 1 Fan Air Flow Direction: Back to Front

Power supply 2 (NA - AC - Regular) present, status ok

Power supply 2 Fan Air Flow Direction: Back to Front

Fan 1 ok, speed (auto): [[1]]<->2

Fan 2 ok, speed (auto): [[1]]<->2

Fan controlled temperature: 47.5 deg-C

Fan speed switching temperature thresholds:

Speed 1: NM<----->68 deg-C

Speed 2: 63<-----> 85 deg-C (shutdown)

Fan 1 Air Flow Direction: Back to Front

Fan 2 Air Flow Direction: Back to Front

MAC-Back Temperature Readings:
