Brocade ICX 6650 Hardware Installation Guide User Manual
Page 73
CAUTION
Be sure that the airflow direction of the power supply unit matches that of the installed fan tray.
The power supplies and fan trays are clearly labeled with either a green arrow with an “E” for
exhaust, or an orange arrow with an “I” for intake.
FIGURE 25 Brocade ICX 6650 airflow —front to back (with E-labeled power supply and fan tray)
1.
Intake
2.
Exhaust
FIGURE 26 Exhaust airflow label
FIGURE 27 Brocade ICX 6650 airflow—back to front (with I-labeled power supply and fan tray)
Brocade ICX 6650 Specifications
Brocade ICX 6650 Hardware Installation Guide
71
53-1003083-01
