Yokogawa Data Acquisition with PID Control CX2000 - Manual (Page 58)

58
IM 04L31A01-02E
List of Parameters
<#6 Control (Zone, Graph (, Partial))>
Parameter Selectable Range or Selections Initial Value
First-CH 101 to 118 or 201 to 248 101
Last-CH 101 to 118 or 201 to 248 101
Zone Lower 0% to 95% 0%
Zone Upper 5% to 100% 100%
Division 4, 5, 6, 7, 8, 9, 10, 11, 12, or C10 10
Bar graph Normal or Center Normal
Scale position Off or 1 to 10 1
Partial On/Off Off
Expand 1% to 99% 50%
Boundary Minimum span value + 1 digit to maximum span value – 1 digit or minimum 0.1
scale value + 1 digit to maximum scale value – 1 digit (when the channel is set
to scaling or square root computation)
<#7 Math (Color)>
Parameter Selectable Range or Selections Initial Value
CH31, CH41, CH51 Red, green, blue, blue violet, brown, orange, Red
yellow-green, light blue, violet, gray,
lime, cyan, dark blue, yellow, light gray, or purple
CH32, CH42, CH52 Same as above Green
CH33, CH43, CH53 Same as above Blue
CH34, CH44, CH54 Same as above Blue-violet
CH35, CH45, CH55 Same as above Brown
CH36, CH46, CH56 Same as above Orange
CH37, CH47, CH57 Same as above Yellow-green
CH38, CH48, CH58 Same as above Light blue
CH39, CH49, CH59 Same as above Violet
CH40, CH50, CH60 Same as above Gray
<#8 Math (Zone, Graph (, Partial))>
Parameter Selectable Range or Selections Initial Value
First-CH 31 to 60 31
Last-CH 31 to 60 31
Zone > Lower 0% to 95% 0%
Zone > Upper 5% to 100% 100%
Graph > Division 4, 5, 6, 7, 8, 9, 10, 11, 12, or C10 10
Graph > Bar graph Normal or Center Normal
Graph > Scale position Off or 1 to 10 1
Partial On/Off Off
Expand 1% to 99% 50%
Boundary Minimum span value + 1 digit to maximum span value – 1 digit or minimum 0.00
scale value + 1 digit to maximum scale value – 1 digit (when the channel is set
to scaling or square root computation)
#5 Save/Load, Clear data
Parameter Selectable Range or Selections Initial Value
#1 Save settings – –
#2 Load settings – –
#3 Save data – –
#4 Load display data – –
#5 Load event data – –
#6 File list – –
#7 Delete – –
#8 Format – –
#9 Clear data – –
