<#3 AUX (Auto message, Display position)>
Parameter Selectable Range or Selections Initial Value
AUX (Auto message, Display position) > On, Off On
Auto message for program Run/Reset On/Off
AUX (Auto message, Display position) >
1 to 6 Loop 1 to 6: 1 to 6
Program display position > Position > Loop 1 to 6
AUX (Auto message, Display positin) >
On, Off Off
Auto change to program run display
<#4 AUX (Event group)>
Parameter Selectable Range or Selections Initial Value
AUX (Event group) > Pattern number 1 to 4 (/PG1) or 1 to 30 (/PG2) 1
AUX (Event group) > 1 to 5 On, Off On
AUX (Event group) > On 1 to 5 > Kind PVEvent, TimeEvent Time Event
AUX (Event group) > Number 01 to 05 1 to 5: 01 to 05
#8 Detailed settings (#7 when the program control function is OFF)
<#1 Control function>
Parameter Selectable Range or Selections Initial Value
Control function > Loop number 1 to 6 1
Control function > SP Tracking Off/On On
Control function > PV tracking On/Off Off
Control function > Target setpoint limiter > Lower EU (0.0% to 100.0%) of the measurement span –200.0
Control function > Target setpoint limiter > Upper EU (0.0% to 100.0%) of the measurement span 1370.0
Control function > Output velocity limiter On/Off Off
Enter the value for On: 0.1%/s to 100.0%/s 100.0%/s
Control function > Anti-reset windup Auto or Manual Auto
Enter the value for Manual: 50.0% to 200.0% 100.0%
<#2 Hysteresis (Alarm)>
Parameter Selectable Range or Selections Initial Value
Hysteresis (Alarm, PV event) > Alarm > Loop number 1 to 6 1
Hysteresis (Alarm, PV event) > Alarm > Hysteresis1 to 4 EUS (0.0% to 10.0%) of the measurement span 7.8
<#3 DIO monitor and operation setting>
Parameter Selectable Range or Selections Initial Value
DIO monitor and operation setting > 01 to 36 01
DIO entry number
DIO monitor and operation setting > On/Off
On, Off Off
DIO monitor and operation setting > Kind DI-1, DO-1, DO-2, DIO-11, DIO12, DO-2P, DI-1
DIO-12P
DIO monitor and operation setting > SW number SW001 to SW036 SW001
DIO monitor and operation setting > DO number > DO001 to DO006, DO101 to DO106, DO001
ON DO201 to DO206, RO001 to RO012,
DIO monitor and operation setting > DO number > DO001 to DO006, DO101 to DO106, DO001
OFF DO201 to DO206, RO001 to RO012,
DIO monitor and operation setting > DI number DI001 to DI006, DI101 to DI106, DI001
DI201 to DI206, RI001 to RI012,
DIO monitor and operation setting > Tag Up to 8 alphanumeric characters –
DIO monitor and operation setting > Tag comment Up to 8 alphanumeric characters –
DIO monitor and operation setting > Up to 8 alphanumeric characters –
Operation property >ON > Label
DIO monitor and operation setting >
Red, green, blue, blue violet, brown, orange, yellow-green, Red
Operation property >ON > Color light blue, violet, gray, lime, cyan, dark blue, yellow,
light gray, or purple
DIO monitor and operation setting > Up to 8 alphanumeric characters –
Operation property >OFF > Label
DIO monitor and operation setting >
Red, green, blue, blue violet, brown, orange, yellow-green, Red
Operation property >OFF > Color light blue, violet, gray, lime, cyan, dark blue, yellow,
light gray, or purple
List of Parameters
