Thank you for purchasing the CX2000. This operation guide briefly explains the main
operations related to the loop control function of the CX2000. For information about all
the functions excluding the communication functions, installation and wiring procedures,
operating procedures, and handling precautions of the CX2000, see the electronic
manual CX2000 User’s Manual (IM 04L31A01-01E) provided on the accompanying CD-
ROM. The following five manuals are provided in addition to this manual and the CX2000
User’s Manual. Read them along with this manual.
Electronic Manuals Provided on the Accompanying CD-ROM
Manual Title Manual No. Description
CX1000/CX2000 Communication IM 04L31A01-17E Describes the communication functions of the
Interface User’s Manual CX1000/CX2000 using the Ethernet/serial interface.
Paper Manuals
Manual Title Manual No. Description
CX2000 Installation and IM 04L31A01-71E Describes concisely the installation procedures and
Connection Guide wiring procedures of the CX2000.
Precautions on the Use IM 04L31A01-72E Precautions regarding the use of the CX1000/CX2000.
of the CX1000/CX2000
Control of Pollution Caused IM 04L31A01-91C Gives a description of pollution control.
by the CX1000/CX2000
DAQSTANDARD Manuals
All manuals other than IM 04L41B01-66EN are contained in the DAQSTANDARD CD.
Manual Title Manual No.
DAQSTANDARD Data Viewer User’s Manual IM 04L41B01-63EN
DAQSTANDARD Hardware Configurator User’s Manual IM 04L41B01-64EN
Installing DAQSTANDARD IM 04L41B01-66EN
Note
• This manual provides information on the CX2000, style number “S3.”
• The contents of this manual are subject to change without prior notice as a result of continuing
improvements to the instrument’s performance and functions.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its
contents. However, should you have any questions or find any errors, please contact your
nearest YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without Yokogawa’s
permission is strictly prohibited.
• The TCP/IP software of this product and the document concerning the TCP/IP software have been
developed/created by YOKOGAWA based on the BSD Networking Software, Release 1 that has
been licensed from the Regents of the University of California.
Trademarks
• vigilantplant, DAQSTATION, and Daqstation are registered trademarks of Yokogawa Electric
Corporation.
• Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
• Adobe and Acrobat are registered trademarks or trademarks of Adobe Systems Incorporated.
• Company and product names that appear in this manual are registered trademarks or
trademarks of their respective holders.
• The company and product names used in this manual are not accompanied by the registered
trademark or trademark symbols (® and TM).
Revisions
1st Edition February, 2002 4th Edition June, 2003
2nd Edition April, 2002 5th Edition May, 2007
3rd Edition January, 2003 6th Edition June, 2010
6th Edition: June 2010 (YK)
All Rights Reserved, Copyright © 2002 Yokogawa Electric Corporation
