Yokogawa Data Acquisition with PID Control CX2000 - Manual (Page 56)

56
IM 04L31A01-02E
Set mode
#1 Range, Alarm
Parameter Selectable Range or Selections Initial Value
First-CH 01 to 20 01
Last-CH 01 to 20 01
Range > Mode Volt, TC, RTD, Scale, Delta, DI, Sqrt, or Skip Volt
Range > Range 20 mV, 60 mV, 200 mV, 2 V, 6 V, 20 V, 50 V, 2 V
R, S, B, K, E, J, T, N, W, L, U, PLATI, PR, Wre,
PT, JPT, Level, or Cont
Range > Span Lower – –2.000
Range > Span Upper – 2.000
Alarm > 1 to 4 On/Off Off
Alarm > Type H: High limit, L: Low limit, R: Rate-of-change, H
T: Delay high, t: Delay low
Alarm > Value – 0.000
Alarm > Relay On/off On/Off Off
Alarm > Relay Number I01 to I06, DO001 to DO006, DO101 to DO106, I01
DO201 to DO206, RO001 to RO012, or
SW001 to SW036
Alarm > Detect On/Off On
#2 Tag, Moving average, Alarm delay
Parameter Selectable Range or Selections Initial Value
First-CH 01 to 20, 101 to 118, or 201 to 248 01
Last-CH 01 to 20, 101 to 118, 201 to 248 01
Tag Up to 16 alphanumeric characters 01
Moving average > Count Off, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, or 16 Off
Alarm delay > Time 1 s to 3600 s 10 s
#3 Trend/Save interval, Message, File, User key, DST
Parameter Selectable Range or Selections Initial Value
Trend/Save interval > Time/div 1 min, 2 min, 5 min, 10 min, 20 min, 30 min, 1 h, 1 min
2 h, 4 h, or 10 h
Trend/Save interval > Auto save interval 10 minutes to 31 days 1h
Message > Characters No. 1 to No. 8 Up to 16 alphanumeric characters –
File > Header Up to 32 alphanumeric characters –
File > Directory name Up to 8 alphanumeric characters DATA0
File > Save data Unsave or All All
USER key > Action None, Trigger, AlarmACK, MathStart/Stop, AlarmACK
MathReset, ManualSample, Message1 - Message8,
or Snapshot
Daylight saving time (YY/MM/DD HH) > Summer Off/On Off
Daylight saving time (YY/MM/DD HH) > Winter Off/On Off
#4 Display
<#1 Group set, Trip line>
Parameter Selectable Range or Selections Initial Value
Group number 1 to 10 1
Group set > Group name Up to 16 alphanumeric characters GROUP 1
Group set > CH set – 01-10
Group set > Trip line > No. 1 to No. 4 On/Off Off
Group set > Trip line > Position 0% to 100% 100%
Group set > Trip line > Color Red, green, blue, blue violet, brown, orange, yellow-green, light blue, No.1: Red, No.2: Green,
violet, gray, lime, cyan, dark blue, yellow,light gray, or purple No.3: Blue, No.4: Yellow
List of Parameters
