55
IM 04L31A01-02E
<#4 DI/DO label setting>
Parameter Selectable Range or Selections Initial Value
DI/DO label setting > Module CTRL1-DI, CTRL2-DI, CTRL3-DI, EXT1-RI, CTRL1-DI
CTRL1-DO, CTRL2-DO, CTRL3-DO, EXT1-RO
DI/DO label setting > DI001 to DI006 > Label Up to 16 alphanumeric characters DI001 to DI006
DI/DO label setting > DI101 to DI106 > Label Up to 16 alphanumeric characters DI101 to DI106
DI/DO label setting > DI201 to DI206 > Label Up to 16 alphanumeric characters DI201 to DI206
DI/DO label setting > RI001 to RI006 > Label Up to 16 alphanumeric characters RI001 to RI006
DI/DO label setting > DO001 to DO006 > Label Up to 16 alphanumeric characters DO001 to DO006
DI/DO label setting > DO101 to DO106 > Label Up to 16 alphanumeric characters DO101 to DO106
DI/DO label setting > DO201 to DO206 > Label Up to 16 alphanumeric characters DO201 to DO206
DI/DO label setting > RO001 to RO006 > Label Up to 16 alphanumeric characters RO001 to RO006
#9 Detailed settings (#8 when the program control function is OFF)
<#1 PV/SP math, Retransmission>
Parameter Selectable Range or Selections Initial Value
PV/SP math, Retransmissin > Loop number 1 to 6 1
PV/SP math, Retransmissin > PV/SP PV, PV1, PV2, SP Value depending on the
(Depending on the control mode) control mode
PV/SP math, Retransmissin > Mode On/Off Off
PV/SP math, Retransmissin > Up to 120 alphanumeric characters Previously determined
Calculation expression control input channel No.
PV/SP math, Retransmissin > PV range > -30000 to 30000 (upper-lower ≤ 30000) Measurement range
Lower-limit of calcuration expression
initial vlue
PV/SP math, Retransmissin > PV range > -30000 to 30000 (upper-lower ≤ 30000) Measurement range
Upper-limit of calcuration expression
initial vlue
PV/SP math, Retransmissin > Unit Up to 6 alphanumeric characters –
PV/SP math, Retransmissin > PV swithing > Lower -30000 to 30000 (upper-lower ≤ 30000) Lower limit of PV range
PV/SP math, Retransmissin > PV swithing > Upper -30000 to 30000 (upper-lower ≤ 30000) Upper limit of PV range
PV/SP math, Retransmissin > Math error Over, Under Over
<#2 Logic math>
Parameter Selectable Range or Selections Initial Value
Logic math > Setting number 1-6, 7-12, 13-18, 19-24, 25-30 1-6
Logic math > Relay Off, DO001 to DO006, DO101 to DO106, Off
DO201 to DO206, Ro001 to RO012,
SW001 to SW036
Logic math > Calculation expression Up to 120 alphanumeric characters –
<#3 Constant>
Parameter Selectable Range or Selections Initial Value
Constant > W01 to W36 –9.9999E+29 to –1.0000E–30, 0, 1
1.0000E–30 to 9.9999E+29
List of Parameters
