List of Parameters
Below is a list of parameters for the model with the various function options. However,
settings related to the program control function option are not given.
Basic Setting Mode
#1 Alarm, A/D, Temperature
Parameter Selectable Range or Selections Initial Value
Alarm > Reflash On/Off Off
Alarm > Relay > AND None, I01, I01-I02, I01-I03, ... , I01-I35, or I01-I36 None
Alarm > Action Energize or Deenergize Energize
Alarm > Behavior Hold or Nonhold Nonhold
Alarm > Indicator Hold or Nonhold Nonhold
Alarm > Rate of change > Increase/Decrease 1 to 15 1
Alarm > Hysteresis On/Off On
A/D Integrate > Integrate Auto, 50 Hz, 60 Hz, or 100 ms Auto
A/D > Scan interval 1 s or 2 s 1 s
A/D > First-CH 01 to 20 * 01
A/D > Last-CH 01 to 20 * 01
A/D > Burnout set Off, Up, or Down Off
A/D > RJC Internal or External Internal
A/D > Volt (uV) –20000 µV to 20000 µV 0 µV
Temperatire > Unit C or F C
* 01 to 10 on models with 10 measurement channels.
#2 Memory, Memory and Trend, Memory Timeup
Parameter Selectable Range or Selections Initial Value
Memory > Save Manual or Auto Auto
Memory > Data Display, E+D, or Event Display
Memory > Event > Sample rate 1 s, 2 s, 5 s, 10 s, 30 s, 60 s, 120 s, 300 s, or 600 s 1 s
Memory > Event > Mode Free, Trigger, or Repeat Trigger
Memory > Event > Block 1, 2, 4, 8, or 16 1
Memory > Event > Data length 3 minutes to 31 days 1 h
Memory > Event > Pre-trigger 0, 5, 25, 50, 75, 95, or 100 0
Memory > Event > Trigger > Key On/Off On
Memory > Event > Trigger > External On/Off Off
Memory > Event > Trigger > Alarm On/Off Off
Memory and trend > Meas/Math/Loop CH Meas CH, Math CH, Int CH, or Ext CH Meas CH
Memory and trend > First-CH Meas CH: 01 to 20 1 , Math CH: 31 to 60 2 , 01
Int CH : 101 to 106 3 , or Ext CH: 201 to 248
Memory and trend > Last-CH Meas CH: 01 to 20 1 , Math CH: 31 to 60 2 , 01
Int CH : 101 to 106 3 , or Ext CH: 201 to 248
Memory and trend > On/Off On/Off On
Memory timeup > Timeup type Off, Hour, Day, Week, or Month Off
Memory timeup > Date 1 to 28 1
Memory timeup > Time (hour) 0 to 23 0
1 01 to 10 on models with 10 measurement channels.
2 Can be specified only on models with the computation function option.
3 The maximum channel number depends on the maximum number of control loops.
#3 Keylock
Parameter Selectable Range or Selections Initial Value
Keylock > Use/Not Use/Not Not
Keylock > Password Up to 6 alphanumeric characters –
Keylock > Keys such as START Free or Lock Free
Key lock > Soft keys such as ALARM ACK Free or Lock Free
Key lock > Control settings such as the input range Free or Lock Free
