9 - 1
IM 11G02N01-01E
1. Standard specifications
Measurable gas components and measuring range:
• Max. 5 components measurement
including O
2
.
• Measuring range ratio
≤
1:5 (O
2
)
≤
1:25
(except for O
2
)
• For measurable components and
possible combinations of measuring
ranges, refer to Tables 1-(1) to (7).
Principle of measurement:
NO, SO
2
, CO
2
, CO, CH
4
;
Non-dispersion infrared-ray absorption
method
Single light source and double beams
(double-beam system)
O
2
; Paramagnetic O
2
sensor (built in) or zir-
conia O
2
sensor (externally installed)
Measured value indication:
Digital indication in 4 digits
(LCD with back light)
• Instantaneous value of each component
• Instantaneous value after O
2
correction
(only in NO, SO
2
, CO measurement
with O
2
)
• Average value after O
2
correction
(only in NO, SO
2
, CO measurement
with O
2
)
• O
2
average value
Analog output signals:
* Inputs/outputs of analog signals are
possible by combining with the input/
output terminal module.
4 to 20mA DC or 0 to 1V DC,
non-isolated output ; 12 points max.
max.load
550
Ω
. for 4 to 20 mA DC
min.load 100k
Ω
. for 0 to 1V DC
* Refer to Table 2, for the channel No. of
displayed values and analog output
signals.
Analog input signal:
For signal input from externally installed
O
2
sensor.
Signal requirement;
(1) Signal from Zirconia O
2
sensor (when
ZX8D ء C or ZX8D ء D)
(2) 0 to 1V DC from an O
2
sensor Input
section is not isolated. This feature is
effective when an O
2
sensor is not
built in.
(Depend on O
2
input signal, measured
concentration indication and O
2
conver-
sion.)
9. SPECIFICATIONS
9.1 General specifications
Minimum range Maximam range
CO
2
CO
CH
4
O
2
(built in)
O
2
(External
Zirconia)
0 – 50ppm
0 – 100vol%
0 – 100vol%
0 – 100vol%
0 – 25vol%
0 – 200ppm
0 – 5vol%
0 – 20ppm
0 – 25vol% 0 – 5vol%
NO
SO
2
0 – 50ppm
0 – 5000ppm
0 – 10vol%
0 – 50ppm
Relay Contact output:
1a contact (250V AC/2A, resistive load)
Instrument error, calibration error,
range identification, auto calibration
status, pump ON/OFF, peak alarm.
1c contact (250V AC/2A, resistive load
selectable 6 outputs)
High/Low limit alarm contact output.
Power disconnection alarm.
* All relay contacts are isolated mutually
and from the internal circuit.
Contact input: No-voltage contact (ON/0V, OFF/5V
DC, 5mA flowing at ON)
Remote range switch, auto calibration
remote start, remote holding, average
value resetting, pump ON/OFF
Isolated from the internal circuit with
photocoupler. Contact inputs are not iso-
lated from one another.
Transmission output:
Solenoid valve drive signal for automatic
calibration.
Transistor output (100mA or less)
Power supply: Voltage rating ; 100V to 240V AC
Allowable range ; 85V to 264V AC
Frequency
; 50Hz/60Hz
Power consumption; 250VA max.
Inlet
; Conform to EN60320
Protection Class I type
Operation conditions:
Ambient temperature ; -5˚C to 45˚C
Ambient humidity
; 90% RH max.,
non-condensing
Storage conditions:
Ambient temperature ; -20˚C to 60˚C
Ambient humidity
; 100% RH max.,
non-condensing
Dimensions (H ЧЧЧЧЧ W ЧЧЧЧЧ D):
Analyzer main unit;
177 x 483 x 578mm (Excluding handles.)
Input/output terminal module;
164 x 318 x 55mm
Mass: Approx. 22 kg (only Analyzer)
Finish color: Front panel ; Off-white (Munsell 10Y7.5/
0.5 or equivalent)
Casing; Steel-blue (gray)
Enclosure: Steel casing, for indoor use
Material of gas-contacting parts:
Gas inlet/outlet; SUS304
Sample cell; SUS304,chloroprene rubber
Infrared-ray transmitting window; CaF
2
O
2
sensor sample cell : SUS316
Internal piping; Toaron, Teflon
Gas inlet/outlet: Rc1/4 or 1/4NPT internal thread
Purge gas flow rate: 1L/min ( when required)
Installation altitude: 2000 m or less
Safety and EMC conforming standards:
Safety: EN61010-1
Pollution degree 2 (Note)
Installation category II (Note)
Note: Installation category, called over-voltage
category, specifies impulse withstanding
voltage. Category II is for electrical equip-
ment.
Pollution degree indicates the degree of
existence of solid, liquid, gas or other
inclusions which may reduce dielectric
strength. Degree 2 is the normal indoor
environment.
EMC: EN61326
EN61000-3-2
EN61000-3-3
