5.4 General operation
• Measurement mode
The measurement mode can be displayed
up to 5 channels in a single screen. If 5
channels or more are to be displayed in a
single screen, press the
or
key to
scroll the channel one by one.
• User mode displays;
Changeover of Range
Setting about Calibration
Alarm Setting
Setting of Auto Calibration
Setting of Auto Zero Calibration
Setting of Peak Alarm
Parameter Setting.
For the setting contents, refer to
“Chapter 6. Setting and calibration”.
