Yokogawa IR400 User Manual
Page 106
9 - 11
IM 11G02N01-01E
(140)
12
164
154
5
(54.5)
29
316
6-
л
4.5
hole
150
150
8
(280)
1000
Ϯ
30
8
Terminal
block
Terminal
block
Terminal
block
Terminal
block
Terminal
block
Connector
Screw terminals M3.5
Input/output terminal
module connector
Cable for Connecting Input / Output Terminal: K9218SD
(Accessory)
Dimensions for Mounting Input/Output Terminal Module
Mounting hole
Connector
302
150
150
154
142
M4 screw
Cut M4 screw holes at 6 positions.
Drill a rectangular hole of 302
ϫ
142 mm or more in the center.
F05.EPS
Unit: mm
Input/Output Terminal Module: K9218SC (Accessory)
