Wa t l o w S e r i e s S D 3 1
■
43
■
C h a p t e r 9 F a c t o r y
Display Parameter Name
Description
Settings Range
(Integer values for Modbus
in parentheses.)
Default Modbus*
(less 40,001
offset)
Read/Write
Appears if:
Factory Page and Calibration
9
To go to the Factory Page, press both the Down ¯ and Up ¿ keys for six seconds from the Home Page. [`SEt] will
appear in the display after three seconds. Continue to hold both keys until [FAct] appears in the display.
• Press the Down ¯ or Up ¿ keys to move through the Factory Page parameters.
• To view or change a parameter value, press and hold the ß Key.
• Press the Down ¯ or Up ¿ keys to change the parameter value.
• Press the Infinity Key ˆ at any time to return to the Home Page.
[AMb]
[AMb]
Ambient Temperature
Displays the current calculated ambient
temperature.
-50.0 to 300.0°F
(-50000 - 300000) NA 277 R
278 R Always active.
[A;mn]
[A.Mn]
Minimum Recorded Ambient
Temperature
Displays the minimum recorded ambient
temperature.
-50.0 to 300.0°F
(-50000 - 300000) NA NA Always active.
[A;ma]
[A.MA]
Maximum Recorded Ambient
Temperature
Displays the maximum recorded ambient
temperature.
-50.0 to 300.0°F
(-50000 - 300000) NA NA Always active.
[DSPL]
[dSPL]
Display Intensity
Increase or decrease the brightness of the
upper and lower display.
15 to 100% duty 100 NA Always active.
[A;Ot1]
[A.Ot1]
Output 1 Process Value
Monitors Process Output 1 value via
Modbus.
00.00 to 22.00 units
(0000 to 2200) 283 R Process output installed
for Output 1
[rESt]
[rESt]
Restore Factory Calibration
Replaces the user calibration parameters
with the factory calibration parameters.
[~~no] (0)
[~yES] (1) [~~no] (0) 208 R/W Always active.
[Usr;r]
[Usr.r]
Restore User Settings
Restores the customer’s configured set-
tings.
[~~no] (0)
[~yES] (1) [~~no] (0) 209 R/W Always active.
[USr;S]
[USr.S]
Save User Settings
Saves the current customer-configured
settings.
[~~no] (0)
[~yES] (1) [~~no] (0) 210 R/W Always active.
[dFLt]
[dFLt]
Default Parameters
Reset all parameters to their
default values.
[~~no] (0)
[~yES] (1) [~~no] (0) 207 R/W Always active.
[O;ty1]
[O.ty1]
Output 1 Type
Displays the hardware type for Output 1.
[nonE] none (0)
[~~DC] DC/open collect. (1)
[rLAY] mech. relay (2)
[~SSr] solid-state relay (3)
[Proc] process (4) [none] (0) 202 R Always active.
