Display Parameter Name
Description
Settings Range
(Integer values for Modbus
in parentheses.)
Default Modbus*
(less 40,001
offset)
Read/Write
Appears if:
Note: Some values will be rounded off to fit in the four-character display. Full values can be read with Modbus.
* Low register numbers contain the two higher bytes; high register numbers contain the two lower bytes of the four-byte integer.
Decimal precision is implied at three decimal places unless otherwise noted.
** Timer model only (SD31-XXXX-XTXX)
Caution: Writing to registers continuously, such as ramping set points via comms, will damage the SD31 EEPROM memory. See page 59.
[Lgc2]
[Lgc2] Alarm 2 Logic
Select the alarm output condition in the
alarm state.
[AL`C] closed on alarm
[AL`O] open on alarm [AL`C] [Ot`2] is set to [dE;AL]
or
[Pr;AL].
[LAt2]
[LAt2] Alarm 2 Latching
Turn alarm latching on or off.
[nLAt] non-latching - off
[`LAt] latching - on [nLAt] [Ot`2] is set to [dE;AL]
or
[Pr;AL].
[SiL2]
[SiL2] Alarm 2 Silencing
Turn alarm silencing on or off.
[`OFF] off - no silencing
[``On] on - silencing [`OFF] [Ot`2] is set to [dE;AL]
or
[Pr;AL].
[dSP2]
[dSP2] Alarm 2 Message
Displays an alarm message when an
alarm is active.
[`OFF] off - no message
[``On] on - message [``On] [Ot`2] is set to [dE;AL]
or
[Pr;AL].
[ACLF]
[ACLF] AC Line Frequency
Set the frequency of the applied AC line
power source.
[``50] 50 (0)
[``60] 60 (1) [``60] (1) 276 R/W If [Ctr1] or [Ctr2] is
set to {Urtb].
[Unit]
[Unit] Units of Measurement
Set the type of units used for the PID con-
trol parameters.
[``US] US (0)
[``SI] SI (1) [``US] (0) 45 R/W Always active.
[I;Err]
[I.Err] Input Error Latching
Turn input error latching on or off.
[nLAt] non-latching (0) - off
[`Lat] latching (1) - on [nLAt] (0) 90 R/W Always active.
[FAIL]
[FAIL] Input Error Failure Mode
Set the input error failure mode when an
error is detected and the control changes
to manual mode.
[`OFF] off (0) - 0% power
[bPLS] bumpless (1) -
current power level
[Man] manual (2) - fixed
power level
[bPLS] (1) 252 R/W Always active.
[MAn]
[MAn] Input Error Power
Set the manual power level when an in-
put error causes a change to manual
mode.
-100.0 to 100.0%
(-10000 to 10000) 0.0% 253 R/W [FAIL} is set to [Man].
[`dSP]
[ dSP] Display Default
Select which display appears normally
and which display requires pressing the
ß Key to access.
[`Set] set point normally
appears, press
ß Key to
view process value (0)**
[`Pro] process normally ap-
pears, press
ß Key to
view set point value (1)**
[aC;Ti] timer normally ap-
pears, press
ß key to
view process value (2)**
[ti;Ac] process normally ap-
pears, press
ß key to
view timer value (3)**
[ti;SP] set point normally
appears, press
ß Key to
view timer value (4)**
[to;tt] press ß key to
toggle between process and
timer values (5)**
[~Pro] (1) 44 R/W Always active.
