[Ot`1] Output 1 Function
[Ctr1] Control Method 1
[Ftb1] Fixed Time Base 1
[PL`1] Power Limit 1
[PSL1] Output Power Scale Low 1
[PSh1] Output Power Scale High 1
[nLF1] Output Non-linear Function 1
[AO1;U] Analog Output 1 Units
[O1;Lo] Analog Output 1 Scale Low
[O1;hi] Analog Output 1 Scale High
[r1;So] Output 1 Retransmit Source
[r1;Lo] Output 1 Retransmit Low Scale
[r1;Hi] Output 1 Retransmit High Scale
[r1;CO] Output 1 Retransmit Offset
[ti;F1] Output Timer Function 1
[S;M1] Signal Time Minutes 1
[`S;S1] Signal Time Seconds 1
[Ot`2] Output 2 Function
[Ctr2] Control Method 2
[Ftb2] Fixed Time Base 2
[PL`2] Power Limit 2
[PSL2] Output Power Scale Low 2
[PSh2] Output Power Scale High 2
[nLF2] Output Non-linear Function 2
[ti;F2] Output Timer Function 2
[S;M2] Signal Time Minutes 2
[`S;S2] Signal Time Seconds 2
[hyS1] Alarm 1 Hysteresis
[Lgc1] Alarm 1 Logic
[LAt1] Alarm 1 Latching
[SiL1] Alarm 1 Silencing
[dSP1] Alarm 1 Message
[hyS2] Alarm 2 Hysteresis
[Lgc2] Alarm 2 Logic
[LAt2] Alarm 2 Latching
[SiL2] Alarm 2 Silencing
[dSP2] Alarm 2 Message
[ACLF] AC Line Frequency
[Unit] Units of Measurement
[I;Err] Input Error Latching
[FAIL] Input Error Failure Mode
[MAn] Input Error Power
[`dSP] Active Displays
[``rP] Ramp to Set Point Mode
[rP;Sc] Ramp Scale
[rP;rt] Ramp Rate
Addr] Modbus Device Address
[bAud] Baud Rate
[`LOC] Lockout
Setup Page Overview
The Setup Page contains parameters that define
basic controller functions. Go to the Setup Page
for initial configuration or if your application re-
quirements change. Be sure to program the Setup
Page first!
Always press the Infinity Key
ˆ to return to the
Home Page.
You must start from the Home Page.
To go to the Setup Page, press both the Up
¿ and
Down
¯ keys for about three seconds.
•
Press the Down
¯ or Up ¿ keys to move
through the Setup Page parameters.
•
To view a parameter value, press and hold
the
ß Key.
•
To change a parameter value, press and hold
the
ß Key and use the Down ¯ or Up ¿
keys to change the parameter value.
•
Press the Infinity Key
ˆ at any time to re-
turn to the Home Page.
[`SEt]
¯
Setup Page
[`Sen] Sensor Type
[`Lin] Linearization
[`C-F] Temperature Units
[S;deC] Temperature Decimal Places
[P;dEC] Process Decimal Places
[IS;En] InfoSense Enable
[IS;P1] InfoSense Point 1
[IS;P2] InfoSense Point 2
[IS;P3] InfoSense Point 3
[IS;P4] InfoSense Point 4
[Sc;Lo] Process Scale Low
[Sc;hi] Process Scale High
[P1;LE] Process Input Low Error
[P1;HE] Process Input High Error
[rg;Lo] Units Scale Low
[rg;hi] Units Scale High
[SP;Lo] Set Point Low Limit
[SP;hi] Set Point High Limit
[Ftr;E] Enable Input Filter
[FLtr] Filter Value
[ti;En] Timer Enable
[hour] Countdown Time Hours
[Min] Countdown Time Minutes
[`Sec] Countdown Time Seconds
[ti;St] Timer Start Method
[ti;SP] Timer Set Point
[`rdy] Ready Band
[rdy;L] Ready Light Enable
¯
Note: Hardware configuration and programming selections deter-
mine what parameters appear on the Setup Page.
