Wa t l o w S e r i e s S D 3 1
■
21
■
C h a p t e r 5 S e t u p
Note: Some values will be rounded off to fit in the four-character display. Full values can be read with Modbus.
* Low register numbers contain the two higher bytes; high register numbers contain the two lower bytes of the four-byte integer.
Decimal precision is implied at three decimal places unless otherwise noted.
Caution: Writing to registers continuously, such as ramping set points via comms, will damage the SD31 EEPROM memory. See page 59.
Display Parameter Name
Description
Settings Range
(Integer values for Modbus
in parentheses.)
Default Modbus*
(less 40,001
offset)
Read/Write
Appears if:
5
Setup Page
[`Sen]
[ SEn] Sensor Type
Set the analog sensor type.
[``tc] thermocouple (0)
[`rtd] RTD (1)
[`MA] milliam,ps (2)
[uolt] volts (3) [``tc] (0) 70 R/W Always active.
[`Lin]
[ Lin] Thermocouple Linearization
Set the analog input thermocouple
linearization.
[```J] J (0) [```D] D (6)
[```H] K (1) [Pt11] PTII (7)
[```t] T (2) [```R] R (8)
[```E] E (3) [```S] S (9)
[```n] N (4) [```B] B (10)
[```C] C (5)
[```J] (0) 71 R/W [`Sen] is set to [``tc].
[`C-F]
[ C-F] Temperature Units
Set the temperature units for thermocou-
ple and RTD inputs.
[```F] Fahrenheit (0)
[```C] Celsius (1) [```F] (0) 40 R/W [`Sen] is set to [``tc]
or [`rtd].
[S;deC]
[S.dEC] Temperature Decimal Places
Set the decimal places for the displayed
input value for thermocouple and RTD
types.
[```0] (0)
[``0;0] (1) [```0] (0) 41 R/W [`Sen] is set to [``tc]
or [`rtd].
[P;dEC]
[P.dEC] Process Decimal Places
Set the decimal places for the displayed
input value for process types.
[```0] (0)
[``0;0] (1)
[`0;00] (2)
[0;000] (3) [```0] (0) 42 R/W [`Sen] is set to [`mA]
or
[uoLt].
[IS;En]
[IS.En] INFOSENSE TM
Enable the sensor feature, which synchro-
nizes the controller with a Watlow sensor.
[``no] no (0)
[`Yes] yes (1) [``no] (0) 91 R/W Always active.
[IS;P1]
[IS.P1] INFOSENSE TM 1
Set sensor point 1 code.
0 to 999
(0 to 999)
500 92 R/W [IS;En] is set to [`yes].
[IS;P2]
[IS.P2] INFOSENSE TM 2
Set sensor point 2 code.
0 to 999
(0 to 999)
500 93 R/W [IS;En] is set to [`yes].
[IS;P3]
[IS.P3] INFOSENSE TM 3
Set sensor point 3 code.
0 to 999
(0 to 999)
500 94 R/W [IS;En] is set to [`yes].
[IS;P4]
[IS.P4] INFOSENSE TM 4
Set sensor point 4 code.
0 to 999
(0 to 999)
500 95 R/W [IS;En] is set to [`yes].
To go to the Setup Page, press both the Down ¯ and Up ¿ keys for three seconds from the Home Page.
[`SEt] will appear in the display.
• Press the Down ¯ or Up ¿ keys to move through the Setup Page parameters.
• To view or change a parameter value, press and hold the ß Key.
• Press the Down ¯ or Up ¿ keys to change the parameter value.
• Press the Infinity Key ˆ at any time to return to the Home Page.
