Wa t l o w S e r i e s S D 3 1
■
23
■
C h a p t e r 5 S e t u p
Display Parameter Name
Description
Settings Range
(Integer values for Modbus
in parentheses.)
Default Modbus*
(less 40,001
offset)
Read/Write
Appears if:
Note: Some values will be rounded off to fit in the four-character display. Full values can be read with Modbus.
* Low numbers contain the two lower bytes; high numbers contain the two higher bytes of the four-byte integer.
Decimal precision is set in another parameter.
** Timer model only (SD31-XXXX-XTXX)
[ti;En]
[ti.En] Timer Enable
Set to enable the countdown timer func-
tion.
[`~no] no (0)
[~YEs] yes (1) [`~no] (0) 391 R/W Timer model only,
SD31-XXXX-XTXX.
[`Ot1] or [`Ot2]is set
to
[tim].
[hour]
[hour] Countdown Time Hours
Set the number of hours for the count-
down time.
0-99
hours
(0 to 99000) 0 392 R/W Timer model only,
SD31-XXXX-XTXX.
[`Ot1] or [`Ot2]is set
to
[tim].
[Min]
[Min] Countdown Time Minutes
Set the number of minutes for the count-
down time.
0-59
minutes
(0 to 59000) 0 393 R/W Timer model only,
SD31-XXXX-XTXX.
[`Ot1] or [`Ot2]is set
to
[tim].
[`Sec]
[ SEc] Countdown Time Seconds
Set the number of seconds for the count-
down time.
0-59
seconds
(0 to 59000) 0 394 R/W Timer model only,
SD31-XXXX-XTXX.
[`Ot1] or [`Ot2]is set
to
[tim].
[ti;St]
[ti.St] Timer Start Method
Select the method used to start the timer
sequence.
[imd] Immediate (0)
[~rdy] Ready (1)
[rdy;A] Ready Acknowledge
(2)
[PWr] Power Up (3) [imd] (0) 399 R/W Timer model only,
SD31-XXXX-XTXX.
[`Ot1] or [`Ot2]is set
to
[tim].
[ti;SP]
[ti.SP] Timer Set Point
Select what set point is used during tim-
ing.
[~Off] Off (0)
[trac] Track (1)
[PrE;s] Preset (2) [trac] (1) 401 R/W Timer model only,
SD31-XXXX-XTXX.
[`Ot1] or [`Ot2]is set
to
[tim].
[`rdy]
[ rdY] Ready Band
Set the deviation band, in degrees from
set point, that would be considered a
ready condition.
1-9999
degrees
(1000 - 9999000) 10
(10000) *395, 396
R/W Timer model only,
SD31-XXXX-XTXX.
[ti;St] is set to [~rdy]
or [
rdy;A].
[rdy;L]
[rdY.L] Ready Light Enable
When enabled, the ready light will be lit if
the process value is within the ready
band.
[`~no] no (0)
[~YEs] yes (1) [`~no] (0) 400 R/W Timer model only,
SD31-XXXX-XTXX.
[ti;St] is set to [~rdy]
or [
rdy;A].
[Ot`1]
[Ot 1] Output 1 Function
Set Output 1 function.
[`OFF] Off (0)
[Pr;AL] Process Alarm (1)
[dE;;AL] Deviation Alarm (2)
[hEAt] Heat Control (3)
[CooL] Cool Control (4)
[rMt] Retransmit (6)
[tim] Timer (7)** [hEAt] (3) 143 R/W Always active.
