4.46 WATLOW Series 988 User’s Manual Setup Menus, Chapter 4
Setup-Comm
Protocol Type
Select the communications protocol.
• [FULL] selects ANSI X3.28 2.2 - A.3.
• [``on] selects Xon/Xoff.
• [Mod] selects Modbus
[Prot] This prompt appears only on controllers equipped with communi-
cations hardware (98_ _-_ _ _ _-_R_ _, 98_ _-_ _ _ _-_U_ _ or 98_ _-_ _ _ _-
_S_ _).
Default
↓
[FULL] [``On] [mod]
[Prot] [Prot] [Prot]
Address
Select an address for the controller. The computer will use this address
when communicating with this controller.
[Addr] This prompt appears only on controllers equipped with communica-
tions hardware for EIA/TIA-485 and EIA/TIA-422.
If Default
↓ ↓
[`485] [```0]… [``31]
[IntF] [Addr] [Addr]
[`422] [```0]… [```9]
[Intf] [Addr] [Addr]
[Mod] [```0] … [```1]… [`247]
[Intf] [Addr] [Addr] [Addr]
[Prot]
[Addr]
