WATLOW Series 988 User’s Manual 4.25 Setup Menus, Chapter 4
Setup-Output
Output 3
Select the alarm condition for output 3.
• [`AL3] de-energizes output 3 in an alarm condition.
• [AL3n] energizes output 3 in an alarm condition.
[`Ot3] This prompt appears only on controllers equipped with output 3
hardware for a relay (98_ _-_ _ _ _-B_ _ _, 98_ _-_ _ _ _-J_ _ _ or
98_ _-_ _ _ _-K_ _ _) or switched dc (98_ _-_ _ _ _-C_ _ _).
Default
↓
[ `AL3] [AL3n] [``no]
[`Ot3] [`Ot3] [`Ot3]
Alarm 3
Select the alarm type for alarm 3.
•
[`Pr1] uses the process signal from input 1.
• [`dE1] uses a deviation from the input 1 signal.
• [`Pr2] uses the process signal from input 2. This prompt does not
appear if the controller is not equipped with input 2 hardware or if
[`In2] is set to [``no] or [`Ei2].
• [`dE2] uses a deviation from the input 2 signal. This prompt does not
appear if the controller is not equipped with input 2 hardware or if
[`In2] is set to [``no] or [`Ei2].
• [rAtE] uses the rate of change at input 1 in degrees per minute.
[`AL3] This prompt appears only on controllers equipped with output 3
hardware for a relay (98_ _-_ _ _ _-B_ _ _, 98_ _-_ _ _ _-J_ _ _ or
98_ _-_ _ _ _-K_ _ _) or switched dc (98_ _-_ _ _ _-C_ _ _), and with
[`Ot3]
set to [`AL3] or [AL3n].
Default
↓
[`Pr1] [`de1] [`Pr2] [`de2] [rAtE] [``no]
[`AL3] [`AL3] [`AL3] [`AL3] [`AL3] [`AL3]
˜
NOTE:
See Chapter 7 for
more information
on alarms.
[`Ot3]
[`AL3]
