WATLOW Series 988 User’s Manual

4.37

Setup Menus, Chapter 4

Setup-Global

Cascade Action

Select the control action between the inner and outer loop of a cas-
cade system.

• Direct action

[`dir] makes the percent output from the outer loop

directly proportional to the set point of the inner loop (input 2). A 100%
signal in the outer loop will set the inner loop to range high 2

[`rH2]

(Input Menu). A 0% signal in the outer loop will set the inner loop to
range low 2

[`rL2] (Input Menu).

• Reverse action

[`rEU] makes the percent output from the outer loop

inversely proportional to the set point of the inner loop (input 2). A 100%
signal in the outer loop will set the inner loop to range low 2

[`rL2]

(Input Menu). A 0% signal in the outer loop will set the inner loop to
range high 2

[`rH2] (Input Menu).

[CSAC] This prompt appears only on controllers equipped with enhanced
software (98_B-_ _ _ _-_ _ _ _) and with

[CntL] set to [CSCd].

Default

[`dir]

[`rEU]

[CASC]

[CASC]

[CSAC]
