Parameters
Diagnostics Group continued
= R e a d O n l y ; = R e a d / W r i t e ; = Tu r n O n / O f f Wa t l o w M i c r o D I N 5 . 2 7
ON
Diagnostics Group
Model Number ........................................... 5.27
Ambient (CJC) A-to-D Counts .................. 5.27
Input A-to-D Counts .................................. 5.27
RTD Lead Compensation A to D Counts . 5.28
RTD Lead Resistance ................................ 5.28
Proportional Term ..................................... 5.28
Integral Term ............................................. 5.28
Derivative Term ......................................... 5.29
Enter Diagnostics Mode ............................ 5.29
Test Displays ............................................. 5.29
Test Outputs .............................................. 5.29
Model Number
• Read the model number of the controller.
• Read only
• Modbus: 000
Range
8568 (ASCII ‘uD’)
Default
none
Active
always
Ambient (CJC) A-to-D Counts
• Read the raw ambient channel, analog-to-digital signal counts.
• Read only
• Modbus: 1501
Range
0 to 65535
Default
none
Active
always
Input A-to-D Counts
• Read the raw input analog-to-digital converter counts.
• Read only
• Modbus: 1504
Range
0 to 65535
Default
none
Active
always
ç
CAUTION:
Avoid writing
continuously to
EEPROM memory.
Continuous writes
may result in
premature control
failure, system
downtime and
damage to
processes and
equipment.
See Disable Non-
volatile Memory
(System Group).
