4 . 4 Wa t l o w M i c r o D I N
Input
Calibration Offset
Calibration offset allows a device to compensate for an inaccurate sensor, lead
resistance or other factors that affect the input value. A positive offset increases
the input value, and a negative offset decreases the input value.
The input offset value can be viewed or changed with Calibration Offset (Input
Group).
Figure 4.4 — Calibration Offset
Features
Time
Temperature
Temperature Reading
from Sensor
Actual Process Temperature
Negative Calibration Offset will
compensate for the difference
between the Sensor Reading and
the Actual Temperature.
