Parameters
5 . 8 Wa t l o w M i c r o D I N = R e a d O n l y ; = R e a d / W r i t e ; = Tu r n O n / O f f
ON
Control Output Group – Monitor
Output Power
• Monitor the control output power level. This can limit PID Output
Power (PID Group).
• Read only
• Modbus: 103
Range
heat: 0.0 to 100.0
cool: -100.0 to 0.0
Default
none
Active
always
Control Output Hardware
• Read the control output hardware type.
• Read only
• Modbus: 16
Range
3: dc
Default
3
Active
always
Control Output Group – Setup
Control Output Function
• Select whether the control output will control for heating or
cooling.
• Read/write
• Modbus: 700
ç
CAUTION:
Avoid writing
continuously to
EEPROM memory.
Continuous writes
may result in
premature control
failure, system
downtime and
damage to
processes and
equipment.
See Disable Non-
volatile Memory
(System Group).
Control Output Group
Monitor
Output Power ..............................................
5.8
Control Output Hardware .......................... 5.8
Setup
Control Output Function ............................
5.8
Power Limit Set Point ................................. 5.9
High Side Power .......................................... 5.9
Low Side Power ........................................... 5.9
Fixed Manual Output ................................ 5.10
