PS-3650A / PS-3651A User Manual
5-8
5.3.2 Special Application Program Features
The special programs designed for the PS-A unit are located in the following folders. Here, it is assumed that
the [Proface] folder has already existed on the hard disk of the PS-A unit.
„ API-DLL
These dynamic link libraries allow users to access RAS features that operates on the PS-A via custom-made
applications. The following three types are available.
‹ Shared Memory Access: Smonras.dll
This dynamic link library allows users to access shared memory via remote RAS features.
For details, refer to the API Reference Manual.
‹ RAS Features: Ioctl.dll
This dynamic link library allows users to access RAS features that operates on the PS-A via custom-made PS-A
applications.
For details, refer to the API Reference Manual.
‹ Backlight Control: Blioctl.sll
This dynamic library allows User-created applications to utilize the PS-A backlight control feature that oper-
ates on the PS-A.
For details, refer to the API Reference Manual.
File Name Windows
®
XP Windows
®
2000
Smonras.dll
C:\Windows\System32 C:\Winnt\System32
Ioctl.dll
Blioctl.dll
Backlight Control.scr
BlBright.cpl
Disp.exe C:\Proface\Disp
Keyclick.exe C:\Proface\Keyclick
SystemMonitor.exe C:\Proface\Sysmon
SmSRvCPL.cpl C:\Windows\System32 C:\Winnt\System32
Sysmon.sys C:\Windows\System32\Drivers C:\Winnt\System32\Drivers
• To uninstall the installed utility software, select [Add or Remove Programs] from Control Panel,
and then select [PS-3650A Series Driver and Utility] to remove it.
