Proface APL3000B - Node Box PC - Manual (Page 100)

Chapter 5 Setting up Software
5-11
5.4 Cautions When Using Windows
®
2000/Windows
®
XP
Do the following process if necessary.
5.4.1 Automatic System Log-on Setup
This setting allows users to simplify password entry at startup.
„ Windows
®
2000
(1) Double-click on the [Control Panel]’s [User and Password] icon.
(2) Designate the automatic logon user, and deselect the [User must enter the user name and password to use
this computer] checkbox.
(3) Click on the [Advanced] tab, and deselect the [Require users to press Ctrl +Alt + Del keys before log-
ging on] checkbox.
(4) Click the [Apply] button. Next, when the automatic logon dialog box appears, enter the password.
„ Windows
®
XP
(1) Select [Run] from the [Start] screen.
(2) Enter “Control userpasswords2”, and click [OK].
(3) Deselect the [User must enter the user name and password to use this computer] checkbox and click
[Apply].
(4) Enter the user name and password for automatic logon and click [OK].
5.4.2 Uninterrupted Power Supply System (UPS)
Be sure to shut down your OS (Windows
®
2000 or Windows
®
XP) before turning off your machine. Also, use
of an uninterrupted power supply is recommended to protect your data from accidental power failures.
An uninterrupted power supply that supports Windows
®
will give you sufficient time to shut down your sys-
tem safely by changing into the power supply for the backup in case of a power failure, and can even be set up
to automatically shut down your Windows
®
OS.
The PS-A unit, however, cannot be used with a 2-Step Inverter Output type uninterrupted power supply. Be
sure the unit is a sine-output type power supply. For details, consult your local UPS system dealer.
Pro-face support site, “Otasuke Pro!” also supply the battery unit for PS-A. Visit “Otasuke Pro!” to download
battery unit driver for PS-3650A series.
URL http://www.pro-face.com/otasuke/
• If automatic logon is not used, a USB keyboard is required to logon.
