Chapter 6 PS-A Monitoring Features
6-3
Error Notification
Also, when either the one of the above mentioned alarm occurs, or an external signal input is received, the fol-
lowing types of alarm processing output signals and features are supported by the PS-A.
Use the included System Monitor feature (utility software) to enable/disable the monitoring features and to set
the alarm processing details.
In addition, you can use the included dynamic link library (API-DLL) to access the RAS features from user-
created applications.
External Output Signal
General Purpose Output (DOUT 2-bit)
Various Processing
Functions
LED Indicator (2 colors, 1 lamp)
The three-color LED on the front face is used to indicate the PS-A system
conditions. It is also used as a power ON/OFF indicator.
Pop-up Message Output
This feature displays the system status via a Windows
®
pop-up message.
Buzzer Output
This feature uses the PS-A unit’s built-in speaker to alert the operator about
the system status.
System Shutdown
This feature shuts down the PS-A unit’s OS.
System Reset
This feature resets the system when the Watchdog Timer reaches “time up”.
SEE
6.3 Monitoring the PS-A Status (page6-10)
SEE
Otasuke Pro! “PS-A Reference Manual”
URL http://www.pro-face.com/otasuke/
SEE
External Input Signals (page6-5)
SEE
