Chapter 6 PS-A Monitoring Features
6-13
When an Error Occurs
(1)
A buzzer sounds and a pop-up message is displayed.
(2)
An “
×” mark appears on the icon in the System Tray, which indicates an error status, and the icon blinks.
You can see the description of the error by double-clicking the icon.
•
The Error Action is performed only one time when an error is detected for each monitoring item.
•
To stop the buzzer, click the [Buzzer Off] button in the pop-up message dialog box.
If the pop-up message is hidden, click the [Buzzer Off] button displayed in the System Monitor
screen.
•
You can also display the [System Monitor] screen by pressing [Show Window] on the pop-up
message window.
•
When you check the [Show this message after an hour] check box and press the [OK] button, the
pop-up message window will close and will not open for an hour.
• Once an error is detected, the System Monitor holds the “error” status. (Icon
display indicating error detection) To recover from the error status, press the
[Reset] button on the System Monitor screen or turn off the PS-A. After that,
perform maintenance service for removing the cause of the error factor, and then
turn on the power again.
Icon display on start-ups
Icon display when an error is detected.
