What You Will Need
The table, below, lists the items necessary to program a Maple Systems OIT Family Operator
Interface Terminal and then connect it to your ASCII host.
OIT3160/OIT4160 OIT3600 All Other Models
Configuration Software OITware-200 OITware-200 OITware-200
Configuration Cable (OIT to PC) 7431-0049 7431-0048 7431-0049
Personal Computer* User Provided User Provided User Provided
Power Cable 6030-0009 Not Required 7431-0050A
1.2 Amp, 24 VDC Power Supply** User Provided User Provided User Provided
ASCII Host User Provided User Provided User Provided
Communication Cable
(OIT to ASCII host)
See Appendix B
* Computer requirements include at least a 486SX/33MHz PC, 4MB RAM, 4MB available
hard disk space, VGA graphics card, Microsoft Windows 3.1, and one available serial port.
** The OIT4400 and OIT4450 require a fast start power supply.
