Figure 4-11: power cable to motherboard connection – IEI Integration NANO-945GSE v2.00 User Manual
Page 87
NANO-945GSE EPIC Motherboard
Page 87
Figure 4-11: Power Cable to Motherboard Connection
Step 3:
Connect Power Cable to Power Supply. Connect one of the 4-pin (1x4) Molex
type power cable connectors to an AT power supply. See Figure 4-12.
Step 0:
