Figure 4-27: vga connector – IEI Integration NANO-945GSE v2.00 User Manual
Page 104
NANO-945GSE EPIC Motherboard
Page 104
Figure 4-27: VGA Connector
Secure the connector. Secure the DB-15 VGA connector from the VGA monitor to the external
interface by tightening the two retention screws on either side of the connector.
Step 0:
