NANO-945GSE EPIC Motherboard
Page 109
o Count: The number of CPUs on the motherboard
 System Memory: Displays the auto-detected system memory.
o Size: Lists memory size
The System Overview field also has two user configurable fields:
 System Time [xx:xx:xx]
Use the System Time option to set the system time. Manually enter the hours, minutes
and seconds.
 System Date [xx/xx/xx]
Use the System Date option to set the system date. Manually enter the day, month and
year.
5.3 Advanced
Use the Advanced menu (
7
BIOS Menu 2) to configure the CPU and peripheral devices
through the following sub-menus:
WARNING:
Setting the wrong values in the sections below may cause the system
to malfunction. Make sure that the settings made are compatible with
the hardware.
 CPU Configuration (see Section
7
5.3.1)
 IDE Configuration (see Section
7
5.3.2)
 SuperIO Configuration (see Section
7
5.3.3)
 Hardware Health Configuration (see Section
7
5.3.4)
 Power Configuration (see Section
7
5.3.5)
 Remote Access Configuration (see Section
7
5.3.5.2)
 USB Configuration (see Section
7
5.3.7)
