NANO-945GSE EPIC Motherboard

Page 56

31 PETN2 32

SMBDATA

33 PETP2 34

GND

35 GND

36

USBD-

37 N/C

38

USBD+

39 N/C

40

GND

41 N/C

42

N/C

43 N/C

44

RF_LINK#

45 N/C

46

BLUELED#

47 N/C

48

1.5V

49 N/C

50

GND

51 N/C

52

VCC3

Table 3-18: PCIe Mini Card Slot Pinouts

3.3.16 PCI-104 Slot

CN Label:

PC104_PLUS1

CN Type:

120-pin PCI-104 slot

CN Location:

See Figure 3-18

CN Pinouts:

See Table 3-19

The PCI-104 slot enables a PCI-104 compatible expansion module to be connected to the

board.
