NANO-945GSE EPIC Motherboard
Page 134
 Terminal Type
 VT-UTF8 Combo Key Support
These configuration options are discussed below.
 Serial Port Number [COM1]
Use the Serial Port Number option allows to select the serial port used for remote
access.
 COM1 D EFAULT System is remotely accessed through COM1
 COM2 System is remotely accessed through COM2
NOTE: Make sure the selected COM port is enabled through the Super I/O configuration
menu.
 Base Address, IRQ [2F8h,3]
The Base Address, IRQ option cannot be configured and only shows the interrupt
address of the serial port listed above.
 Serial Port Mode [115200 8,n,1]
Use the Serial Port Mode option to select baud rate through which the console redirection
is made. The following configuration options are available
 115200 8,n,1 D EFAULT
 57600 8,n,1
 38400 8,n,1
 19200 8,n,1
 09600 8,n,1
NOTE:
Identical baud rate setting musts be set on the host (a management
computer running a terminal software) and the slave
