NANO-945GSE EPIC Motherboard
Page 37
Fan connector
3-pin wafer CPU_FAN1
Front panel connector
8-pin header F_PANEL1
IDE disk drive connectors (44-pin)
44-pin box header IDE1
Infrared interface (IrDA) connector
5-pin header IR1
Keyboard connector
6-pin wafer KB1
LVDS connector
30-pin crimp LVDS2
LVDS connector
30-pin crimp LVDS1
Parallel port connector
26-pin header LPT1
PCI-104 slot
120-pin socket PC104_PLUS1
PCIe Mini Card slot
PCIe Mini Slot CN4
Serial ATA (SATA) drive connectors
7-pin SATA SATA1
Serial ATA (SATA) drive connectors
7-pin SATA SATA2
RS-232 serial port connector
10-pin header COM3
RS-232 serial port connector
10-pin header COM4
RS-232/422/485 serial port connector
14-pin header COM2
TV Out connector
6-pin header TV1
USB 2.0 connector
8-pin header USB01
USB 2.0 connector
8-pin header USB23
Table 3-1: Peripheral Interface Connectors
3.2.1 External Interface Panel Connectors
6
Table 3-2 lists the rear panel connectors on the NANO-945GSE. Detailed descriptions of
these connectors can be found in Section
6
3.4 on page
6
63.
