NANO-945GSE EPIC Motherboard
Page 85
NOTE:
IEI has a wide range of backplanes available. Please contact your
NANO-945GSE vendor, reseller or an IEI sales representative at
2
[email protected] or visit the IEI website (
2
http://www.ieiworld.com.tw)
to find out more about the available chassis.
4.6.2 Motherboard Installation
To install the NANO-945GSE motherboard into the chassis please refer to the reference
material that came with the chassis.
4.7 Internal Peripheral Device Connections
4.7.1 Peripheral Device Cables
The cables listed in
7
Table 4-9 are shipped with the NANO-945GSE.
Quantity Type
1 Keyboard and Mouse cable
2 SATA drive cable
1 Power cable
1 RS-232 cable
Table 4-9: IEI Provided Cables
Some optional items that can be purchased separately and installed on the
NANO-945GSE include:
 Dual port USB cable
 Parallel port cable
 RS-232/422/485 cable
 ATX power cable
