NANO-945GSE EPIC Motherboard

Page 49

1 RESET# 2 GROUND

3

DATA 7

4

DATA 8

5

DATA 6

6

DATA 9

7

DATA 5

8

DATA 10

9

DATA 4

10

DATA 11

11

DATA 3

12

DATA 12

13

DATA 2

14

DATA 13

15

DATA 1

16

DATA 14

17

DATA 0

18

DATA 15

19 GROUND

20 N/C

21 IDE

DRQ

22 GROUND

23 IOW#

24 GROUND

25 IOR#

26 GROUND

27 IDE

CHRDY 28 GROUND

29 IDE

DACK 30 GROUND–DEFAULT

31 INTERRUPT 32 N/C

33 SA1

34 N/C

35 SA0

36 SA2

37

HDC CS0#

38

HDC CS1#

39 HDD

ACTIVE#

40 GROUND

41 VCC

42 VCC

43 GROUND

44 N/C

Table 3-12: Secondary IDE Connector Pinouts

3.3.11 Infrared Interface Connector (5-pin)

CN Label:

IR1

CN Type:

5-pin header (1x5)

CN Location:

See

6

Figure 3-13

CN Pinouts:

See

6

Table 3-13
