Connector Type Label
Ethernet connector RJ-45 LAN1
Ethernet connector RJ-45 LAN2
Keyboard/mouse PS/2 KB_MS1
RS-232 serial port connector Male DB-9 COM1
Dual USB port USB port USB
VGA port connector 15-pin female VGA1
Table 3-2: Rear Panel Connectors
3.3 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the NANO-945GSE.
3.3.1 5V Power Connector
CN Label: CN3
CN Type: 2-pin wafer (1x3)
CN Location: See Figure 3-3
CN Pinouts: See Table 3-3
The 5V Power Connector provides +5V power output.
