NANO-945GSE EPIC Motherboard
Page 27
LAN
Two Realtek RTL8111E GbE controllers with ASF 2.0
support
COM
Three RS-232 serial ports
One RS-232/422/485 serial port
USB2.0
Six USB 2.0 devices supported:
 Four by onboard pin-headers
 Two by external connectors
Hard Drives
One 44-pin IDE connector connects to two Ultra
ATA33/66/100 devices
SATA Two 1.5 Gbps SATA drives supported
Keyboard/mouse One external PS/2 connector
Parallel Port One 26-pin parallel port connector
Expansion
One PCI-104 expansion slot (PCI bus)
One PCIe mini card (PCIe bus)
Digital I/O
One 8-bit digital input/output connector; 4-bit input/4-bit
output through the ITE IT8718 super I/O
Watchdog Timer
Software programmable 1-255 sec. through the ITE IT8718
super I/O
Infrared
One infrared connector through the ITE IT8718 super I/O.
Supports:
 Serial Infrared (SIR)
 Amplitude Shift Keyed IR (ASKIR)
Power Supply 12V only, ATX and AT power supported
Power Consumption
12V @ 1.53 A
( 1.6 GHz Intel® Atom™ one 2.0 GB DDR2 SO-DIMM )
Temperature 0ºC – 60ºC (32ºF - 140ºF)
