NANO-945GSE EPIC Motherboard
Page 26
1.5 Technical Specifications
NANO-945GSE technical specifications are listed in
6
Table 1-1. See Chapter 2 for details.
Specification NANO-945GSE
Form Factor EPIC
System CPU 45 nm 1.6 GHz Intel® Atom™ N270
Front Side Bus (FSB) 533 MHz
System Chipset
Northbridge: Intel® 945GSE
Southbridge: Intel® ICH7M
Memory
One 200-pin SO-DIMM socket supports one 533 MHz 2.0
GB (max.) DDR2 SDRAM SO-DIMM
CompactFlash® One CompactFlash® Type II socket
Super I/O ITE IT8718
Display
Intel® Graphics Media Accelerator 950
VGA integrated in Intel® 945GSE
HDTV with 1080i maximum resolution supported
Dual LVDS support
18-bit dual channel LVDS integrated in Intel® 945GSE
NANO-942GSELVDS2: 18/24-bit dual-channel supported
with Chrontel CH7308B
BIOS AMI BIOS label
Audio
5.1 channel audio kit with Realtek ALC655 AC'97 codec
7.1 channel HD audio kit with Realtek ALC883 codec
supports dual audio streams
