o System Temperature
 Speed:
o FAN1 Speed
 Voltages:
o VCC3V
o V_core
o +1.05V
o VDDR
o VSB5V
o VSB3V
o VBAT
5.3.7.1 S m a rt Fa n Mo d e Co n fig u ra tio n
Use the Smart Fan Mode Configuration submenu (BIOS Menu 11) to configure the
smart fan temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU Smart Fan control [Auto PWM Mode]
Temperature of Off 75
Temperature of Start 80
Start PWM 30
Slope(Duty Cycle) [4]
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1231. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 11: FAN 1 Configuration
 CPU Sm a rt Fan co n tro l [Au to PWM Mo d e]
Use the CPU Smart Fan control BIOS option to configure the CPU Smart Fan.
