KINO-DH810
P a g e 79

IO=2D8h;
IRQ=10, 11
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10, 11
 Device Mo d e [RS485/RS422]
The Device Mode shows Serial Port 6 provides RS-485/RS-422 communications.
5.3.7 F81866 H/W Mo n ito r
The F8186 H/W Monitor menu (BIOS Menu 10) shows the operating temperature, fan
speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
CPU temperature
:+42 C
System temperature :+31 C
Fan1 Speed :1656 RPM
VCC3V :+3.408 V
V_core :+1.024 V
+1.05V :+1.320 V
VDDR :+1.520 V
VSB5V :+5.040 V
VSB3V :+3.376 V
VBAT :+3.184 V
Enable or Disable Smart
Fan
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.15.1231. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 Temperatures:
o CPU Temperature
