PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 DVI_TMDS_C_DATA2# 2 DVI_TMDS_C_DATA2
3 GND 4 NC
5 NC 6 DVI_DDC_SCLK
7 DVI_DDC_SDATA 8 NC
9 DVI_TMDS_C_DATA1# 10 DVI_TMDS_C_DATA1
11 GND 12 NC
13 NC 14 +5V_DVI
15 GND 16 DVI_HPD
17 DVI_TMDS_C_DATA0# 18 DVI_TMDS_C_DATA0
19 GND 20 NC
21 NC 22 GND
23 DVI_TMDS_C_CLK 24 DVI_TMDS_C_CLK#
C1 NC C2 NC
C3 NC C4 NC
Table 3-26: DVI Connector Pinouts
