KINO-DH810
P a g e 8
S p e c ific a tio n KINO-DH810
TP M 1 x 20-pin (2x10) header
S MBu s 1 x 4-pin (1x4) wafer
Fa n 1 x 4-pin (1x4) CPU fan connector
1 x 4-pin (1x4) system fan connector
S e ria l P o rts 5 x RS-232 (2 on Rear I/O, 3 by pin header)
1 x RS-422/485 by 4-pin wafer
US B P o rts 2 x USB 3.0 (on Rear I/O)
6 x USB 2.0 (2 on Rear I/O, 4 by pin header)
Fro n t P a n e l 1 x Front Panel (Power LED, HDD LED, Speaker, Power
Button, Reset Button)
LAN LED 2 x 2-pin (1x2) header for LAN1 LED, LAN2 LED
S to ra g e
S e ria l ATA 2 x SATA 6Gb/s without raid support
En viro n m e n ta l a n d P o we r S p e c ific a tio n s
P o we r S u p p ly DC input (12V only)
Op e ra tin g Te m p e ra tu re -20ºC ~ 60ºC
Hu m id ity 5% ~ 95% (non-condensing)
P h ys ic a l S p e c ific a tio n s
Dim e n s io n s 170 mm x 170 mm
We ig h t GW/NW 900 g / 450 g
Table 1-1: Technical Specifications
