5.2 Ma in
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version 4.6.5.4
Compliency UEFI 2.3.1; PI 1.2
Project Version SAA2AR11.ROM
Build Date 11/29/2013 08:20:40
iWDD Vendor
iEi
iWDD Version SAA2ET02.bin
Processor Information
Name
Haswell
Brand String Intel(R) Core(TM)
i5-4570S CPU @ 2.90GHz
Frequency
3200 MHz
Processor ID 306c3
Stepping C0
Number of Processors 4Core(s) / 4Thread(s)
Microcode Revision 8
GT Info GT3 (700 MHz)
IGFX VBIOS Version
2170
Memory RC Version 1.4.0.3
Total Memory 4096 MB (DDR3)
Memory Frequency 1600 MHz
PCH Information
Name
LynxPoint
PCH SKU H81
Stepping 05/C2
LAN PHY Revision N/A
ME FW Version 9.0.13.1402
ME Firmware SKU 1.5MB
SPI Clock Frequency
DOFR Support
Supported
Read Status Clock Frequnecy 50 MHz
Write Status Clock Frequnecy 50 MHz
Fast Read Status Clock Frequnecy 50 MHz
System Language
[English]
System Date [Tue 12/03/2012]
System Time [19:43:27]
Access Level Administrator
Choose the system
default language.
----------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save
ESC Exit
Version 2.15.1231. Copyright (C) 2012 American Megatrends, Inc.
