5.4.1 P CH-IO Co n fig u ra tio n
Use the PCH-IO Configuration menu (BIOS Menu 16) to configure the PCH chipset.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Intel PCH RC Version 1.4.0.0
Intel PCH SKU Name H81
Auto Power Button Status
[Enabled(AT)]
> PCH Azalia Configuration
USB SW1 [+5V DUAL]
USB SW2 [+5V DUAL]
PCH Azalia Configuration
settings.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.15.1231. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 16:PCH-IO Configuration
 USB SW1 [+5V DUAL]
Use the USB SW1 BIOS option to select the USB1 power.

+5V The USB power is +5V.

+5V DUAL D EFAULT The USB power is +5V dual.
 USB SW2 [+5V DUAL]
Use the USB SW2 BIOS option to select the USB2 power.

+5V The USB power is +5V.

+5V DUAL D EFAULT The USB power is +5V dual.
