KINO-DH810
P a g e 78

Auto D EFAULT The serial port IO port address and interrupt address
are automatically detected.

IO=2D0h;
IRQ=10
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10

IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11

IO=2D8h;
IRQ=10, 11
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10, 11
 Device Mo d e [RS232]
The Device Mode shows Serial Port 5 provides RS-232 communications.
5.3.6.1.6 S e ria l P o rt 6 Co n fig u ra tio n
 Serial Po rt [En ab led ]
Use the Serial Port option to enable or disable the serial port.

Disabled Disable the serial port

Enabled D EFAULT Enable the serial port
 Ch an g e S ettin g s [Au to ]
Use the Change Settings option to change the serial port IO port address and interrupt
address.

Auto D EFAULT The serial port IO port address and interrupt address
are automatically detected.

IO=2D8h;
IRQ=10
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10

IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11
