3.1.2 P e rip h e ra l In te rfa c e Co n n e c to rs
The table below lists all the connectors on the board.
Co n n e c to r Typ e La b e l
AT/ATX mode select switch switch J_ATX_AT1
Battery connector 2-pin wafer BAT1
Clear CMOS button button J_CMOS1
12V DC-IN power connector 4-pin Molex PWR2
DDR3 SO-DIMM slots DDR3 SO-DIMM slot CHA_DIMM1, CHB_DIMM1
Digital I/O connector 10-pin header DIO1
Display port connector 20-pin box header DP1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (System) 4-pin wafer SYS_FAN1
Front audio connector 10-pin header FRONT_PANEL1
Front panel connector 10-pin header F_PANEL1
Keyboard/Mouse connector 6-pin wafer KB_MS1
LAN LED connector 2-pin header LED_LAN1, LED_LAN2
PCIe x1 slot PCIe x1 slot PCIEX1_1
PCIe Mini card slot PCIe Mini card slot CN2
Power button Push button PWR_SW1
SATA 6Gb/s drive connectors 7-pin SATA connector S_ATA1, S_ATA2
SATA power connectors 4-pin wafer SATA_PWR1, SATA_PWR2
Serial port, RS-422/485 4-pin wafer COM6
Serial port, RS-232 10-pin header COM3, COM4, COM5
