1. Specifications Check
15
1.2 Specification
[1] Max. Speed
There is a limit in the maximum speed of the actuators.
Restriction on Speed (Unit: mm/s)
Stroke [mm]
Type
Motor Type
[W] 300 400 500 600 700 800 900 1000
60 1 to 1250
NM
100 1 to 1250
Stroke [mm]
Type
Motor Type
[W] 300 400 600 800 1000 1500 2000 2500
100 1 to 1250
WM
200 1 to 1250
Stroke [mm]
Type
Motor Type
[W] 1000 1500 2000 2500 3000
LM 400 1 to 1250
HM 400 1 to 2000
[2] Max. Acceleration Speed and Transportable Weight
When the transported weight is low, the acceleration/deceleration can be increased.
Size Slider
Motor Type
[W]
Acceleration/
Deceleration
[G]
Transportable
Weight [kg]
Rated Thrust
[N]
11NM Single 60 0.3 2 29
12NM Double 60 0.3 9 29
11NM Single 100 0.3 3 49
12NM Double 100 0.3 15 49
11WM Single 100 0.3 3 49
12WM Double 100 0.3 15 49
11WM Single 200 0.3 6 98
12WM Double 200 0.3 30 98
11LM Single 400 0.3 15 196
12LM Double 400 0.3 60 196
11HM Single 400 0.3 10 127
12HM Double 400 0.3 40 127
Caution: Do not have the settings of acceleration/deceleration exceeding the rated
values. It may cause vibration, malfunction or shortened life.
